Easy operation Radiator Disassembly Machine
Adopts advanced Disassembly technology, which can quickly separate copper tubes and aluminum fins from waste radiator
Tired of time-consuming manual radiator disassembly that wastes labor and reduces profits? Our Radiator Disassembly Machine eliminates these headaches – it separates copper tubes, aluminum fins, and shells in seconds, turning scrap radiators into high-value recyclables fast.
Radiator Disassembly Machine is designed for recycling scrap radiators (sourced from discarded air conditioners, water tanks, automobiles, or refrigerators) to separate valuable copper tubes and aluminum.
Parameter:
Model | External di#56585emension(mm) | Blade quantity (Pcs) #56585e | Diameter of blade (mm) | Number of platens (per platen) | Diameter of platen (mm) | Power (kw) | Weight (kg) |
RP-850 | 1700*1000*1100 | 65 | 105+100 | 70 | 125 | 7 | 750 |
RP-1200 | 2100*1150*1100 | 117 | 105+100 | 121 | 125 | 7 | 1250 |
How to work:
1. Pre-separation Preparation: Remove the iron sheets on the radiator sides first. Then cut the radiator into neat sections, ensuring each section has a width of 30-40 cm.
2. Feeding & Stripping: Put the cut radiator sections into the machine’s feeder to start the stripping process. The machine supports automatic discharge, no manual handling required.
3. Layer Handling: It can directly peel 1-layer and 2-layer radiators. For radiators with more than 2 layers, use a band saw to cut them into 1-layer or 2-layer sections before feeding.
Final Output & Advantages
- End Products: Pure copper tubes and aluminum foil (no mixed impurities).
- Core Advantage: Achieves a 100% metal recycling rate, making it a highly profitable metal recycling solution.
